Hidden feature of Kubernetes Service
Expose multiple apps on the same LoadBalancer Service
Have you ever wondered what is the difference between defining ports using names or using ports in Kubernetes Service?
The documentation says that you can reference container port names in the targetPort
attribute (https://kubernetes.io/docs/concepts/services-networking/service/#field-spec-ports), so it can look like this: targetPort: 8080
or this targetPort: my-http
.
Let's see it in practice.
Environment information
Kubernetes 1.26 on GKE
For demo purposes, I will use the following Pod to test services:
apiVersion: v1
kind: Pod
metadata:
name: tester
namespace: tests
spec:
containers:
- name: debug
image: nicolaka/netshoot
command: ["/bin/sh"]
args: ["-c", 'trap "exit" TERM; while true; do sleep 1; done']
nicolaka/netshoot
image contains curl
and many more tools.
We will use 2 different Pods which expose the same port number (80). Also, we will use a single Service that routes traffic to these Pods.
We have 4 possibilities
Service\Pod | http as port name | different name as port name |
port number as targetPort | 1 | 2 |
port name as targetPort | 3 | 4 |
Scenario 1.
http
as the port name in containersport number as
targetPort
in the Service
apiVersion: v1
kind: Pod
metadata:
name: nginx
namespace: tests
labels:
type: server-www
spec:
containers:
- name: nginx-container
image: nginx
ports:
- name: http # HERE
containerPort: 80
protocol: TCP
---
apiVersion: v1
kind: Pod
metadata:
name: apache
namespace: tests
labels:
type: server-www
spec:
containers:
- name: apache-container
image: httpd
ports:
- name: http # HERE
containerPort: 80
protocol: TCP
---
apiVersion: v1
kind: Service
metadata:
name: my-service
namespace: tests
spec:
selector:
type: server-www
ports:
- protocol: TCP
port: 80
targetPort: 80 # HERE
Results
Service uses a round-robin to route traffic one by one to each Pod:
tester:~# curl -s -I my-service | grep Server
Server: Apache/2.4.57 (Unix)
tester:~# curl -s -I my-service | grep Server
Server: nginx/1.25.2
tester:~# curl -s -I my-service | grep Server
Server: nginx/1.25.2
tester:~# curl -s -I my-service | grep Server
Server: Apache/2.4.57 (Unix)
The same would when Pods are under the ReplicaSet control, but then they have the same image, so we would not see the difference like the above.
kubectl -n tests describe svc my-service
Name: my-service
Namespace: tests
...
Selector: type=server-www
Port: <unset> 80/TCP
TargetPort: 80/TCP
Endpoints: 10.52.0.28:80,10.52.2.38:80
...
Scenario 2.
different name as the port name in containers
port number as
targetPort
in the Service
apiVersion: v1
kind: Pod
metadata:
name: nginx
namespace: tests
labels:
type: server-www
spec:
containers:
- name: nginx-container
image: nginx
ports:
- name: nginx-port # HERE
containerPort: 80
protocol: TCP
---
apiVersion: v1
kind: Pod
metadata:
name: apache
namespace: tests
labels:
type: server-www
spec:
containers:
- name: apache-container
image: httpd
ports:
- name: apache-port # HERE
containerPort: 80
protocol: TCP
---
# Service YAML the same as in Scenario 1.
Results
The same results as in Scenario 1.
Scenario 3.
http
as the port name in containersport name as
targetPort
in the Service
# Pods YAML the same as in Scenario 1.
---
apiVersion: v1
kind: Service
metadata:
name: my-service
namespace: tests
spec:
selector:
type: server-www
ports:
- protocol: TCP
port: 80
targetPort: http # HERE
Results
The same results as in Scenario 1 and 2.
Scenario 4.
different name as the port name in containers
port name as
targetPort
in the Service
apiVersion: v1
kind: Pod
metadata:
name: nginx
namespace: tests
labels:
type: server-www
spec:
containers:
- name: nginx-container
image: nginx
ports:
- name: nginx-port # HERE - different than apache has
containerPort: 80
protocol: TCP
---
apiVersion: v1
kind: Pod
metadata:
name: apache
namespace: tests
labels:
type: server-www
spec:
containers:
- name: apache-container
image: httpd
ports:
- name: apache-port # HERE - different than nginx has
containerPort: 80
protocol: TCP
---
apiVersion: v1
kind: Service
metadata:
name: my-service
namespace: tests
spec:
selector:
type: server-www
ports:
# HERE
- name: nginx
protocol: TCP
port: 90
targetPort: nginx-port
- name: apache
protocol: TCP
port: 91
targetPort: apache-port
As you can see, the Service has 2 ports definitions. It is because we want to specify 2 different names as targetPort
. Also, we have to choose different port numbers.
Results
# Nginx application is exposed on port 90
tester:~# curl -s -I my-service:90 | grep Server
Server: nginx/1.25.2
tester:~# curl -s -I my-service:90 | grep Server
Server: nginx/1.25.2
tester:~# curl -s -I my-service:90 | grep Server
Server: nginx/1.25.2
# Apache applications is exposed on port 91
tester:~# curl -s -I my-service:91 | grep Server
Server: Apache/2.4.57 (Unix)
tester:~# curl -s -I my-service:91 | grep Server
Server: Apache/2.4.57 (Unix)
tester:~# curl -s -I my-service:91 | grep Server
Server: Apache/2.4.57 (Unix)
kubectl -n tests describe svc my-service
Name: my-service
Namespace: tests
Selector: type=server-www
Type: ClusterIP
...
Port: nginx 90/TCP
TargetPort: nginx-port/TCP
Endpoints: 10.92.0.30:80
Port: apache 91/TCP
TargetPort: apache-port/TCP
Endpoints: 10.92.2.42:80
...
BINGO!
In this scenario we can point each application separately by using different port numbers, but the same Service (also DNS name).
The Service links each container with the related port number.
Conclusion
We can expose multiple different applications (from different Deployments/StatefulSets/ReplicaSets) using a single Service object. They only need to be split by port number on the Service configuration, and they have to use unique port names.
Where is the magic? You can think it's not useful. Yes, it does not make any sense to use this with the service type ClusterIP
.
The magic begins when this is used with type LoadBalancer
in private clusters.
Private clusters in cloud environments (like GKE) need external Load Balancers to expose applications outside. Thanks to this hidden feature you can expose multiple applications behind the same Load Balancer.
There are a few cons of it, for example, cost optimization.
